RSA Chained (Dragon CTF Teaser 2019)25 Sep 2019
In this challenge, we need to recover a message that is encrypted through 4 different RSA keys, while knowing some of the bits of the private keys. In particular, we are given code that generates 4 different RSA keys (of ~2100 bits each), permutes them, encrypts the flag by each of them in succession, and then provides us the encrypted flag. Additionally, we are given the moduli of the keys, as well as the lower half (i.e., least significant 1050 bits) of the private keys. These are given to us in output.txt.
The only other info that is given to us is:
Keys are generated in the standard way with the default setup...
Let's first sketch out how the keys are generated. We name everything using SSA-style (i.e., give new names each time we reassign a variable to a new value) so that we can better keep track of things:
|RSA Modulus||Use||Size (Bits)|
|n1||p1 q1||700 + 1400|
|n2||p2 q2 r2||700 + 700 + 700|
|n3||p3 q3 r2||700 + 700 + 700|
|n4||p4 q4 q4||700 + 700 + 700|
Notice how we have a repeated
r2? This will help us soon.
Another thing to note here is that n1, n2, n3, n4 are not in the order we get them in output.txt – the order we get is in sorted order.
Let's call the keys we get as
ns .. ns, to keep them separate
from n1, … n4. Also, let's called the partial private keys as
nerf_ds .. nerf_ds, since we have only a part of them.
import itertools import gmpy2 with open('./output.txt') as f: data = f.read().strip().split('\n') keys = map(lambda x: map(int, x.split(' ')[1:]), data[0:4]) enc_flag = int(data.split(' ')) ns = map(lambda x: x, keys) nerf_ds = map(lambda x: x, keys)
Recall that there was a repeated
r2. We can recover this, and also
figure out part of the permutations by simply performing a pairwise
GCD of the different moduli.
for a, b in itertools.product(ns, ns): if a >= b: continue gcd = gmpy2.gcd(a, b) if gcd > 1: r2 = gcd print str(r2)[:30] + '...' n2n3 =  for i, a in enumerate(ns): if a % r2 == 0: n2n3.append(a) print i
326199725504488859529927636344... 0 1
Now we know that
n3 (we can, for now, just
arbitrarily pick the order – we'll fix it later if necessary).
This also tells us that
n4 although again
we don't know which is which.
Now let's get to the nerfed private keys.
Since we have the lower half of the private keys, we should be able to get something, right?
Turns out, there is a nice attack when you know the LSBs of the private key: Coppersmith Attack!
Let's re-derive it from scratch, first for the
p*q case (i.e.,
since we'll need to understand its derivation to be able to use it for
n2, n3 and n4.
e*d = 1 (mod phi)
e*d - 1 = k * phi
e*d - 1 = k * ((p-1) * (q-1))
e*d - 1 = k * (p*q - p - q + 1)
e*d - 1 = k * (N - p - q + 1)
e*d*p - q = k * p * (N - p - q + 1)
e*d*p - k*p*(N - p + 1) + k*N = p
e*d*p - k*p*(N - p + 1) + k*N = p (mod M)
(k)*p2 + (d*e - k*N - k - 1)*p + k*N = 0 (mod M)
In the above,
2^1050 which refers to the fact that we only
know the lower 1050 bits of the private key. Since the final equation
M, we actually know all of the values for the quadratic
p, if we simply pick a value for
Since we know that
0 < d < phi, we know that
0 < k <= e. Conveniently,
e is only 1667, which means we only need to try 1667 such quadratic
One small setback- we need to compute the quadratic equation modulo
M. We could use Sage's
solve_mod but for some reason I wasn't
able to really get it to work well (not entirely sure why) so I
decided to implement it myself. What we need to know for this is
Hensel's Lemma. More
particularly, one if its consequences: if we can compute the root of a
f modulo some power of a prime, we can
easily compute the root modulo the next power. There are indeed more
powerful things we can do with this, but this requires more specific
conditions that we don't really have, so let's simply use this fact
for now. I ended up implementing a fairly simply higher-order function
that computes these roots using the most basic way I could think of
# Compute roots of f modulo p^k def roots_by_hensel_lift(f, p, k): assert k >= 1 def M(x): return x % (p ** k) results = set() if k == 1: for i in xrange(0, p): if M(f(i)) == 0: results.add(i) return results assert k > 1 for r in roots_by_hensel_lift(f, p, k - 1): for i in xrange(0, p): if M(f(r + ((p ** (k - 1)) * i))) == 0: results.add(r + ((p ** (k - 1)) * i)) return results
Unfortunately, if we use it for anything larger than some depth, we'll hit the default recursion limit for Python, so let's change it:
from sys import setrecursionlimit setrecursionlimit(10000)
Now we can easily go over each of the keys that we have, and quickly
factor them, as long as they are of the form
p * q (i.e.,
this must be either
ns, let's only run it on these two.
def factor_pq(N, partial_d): e = 1667 for k in range(1, e + 1): A = k B = (partial_d * e) - k * N - k - 1 C = k * N def f(x): return (A * x * x) + (B * x) + C solns = roots_by_hensel_lift(f, 2, 1050) for possible_ans in solns: if N % possible_ans == 0: return possible_ans p1 = factor_pq(ns, nerf_ds) if p1 is not None: print "Found n1 in ns" n1 = ns else: p1 = factor_pq(ns, nerf_ds) assert p1 is not None print "Found n1 in ns" n1 = ns print "p1 =", str(p1)[:30] + '...' assert n1 % p1 == 0 assert n1 != p1 q1 = n1 / p1 print "q1 =", str(q1)[:30] + '...'
Found n1 in ns p1 = 188689169745401648234984799686... q1 = 224327615705283723685555998413...
It takes a minute or so to find the above answer. But yeah, now we
ns and also just learnt that
Let's tackle that now, shall we?
n4 is of the form
pqq, we need to re-derive an attack using the
same technique we used before (Coppersmith's attack). The only
difference here is that we will try to obtain an equation in
because it is easier. Additionally, this equation turns out to be a
cubic equation, but that's ok for us, since Hensel's lemma works here
e*d = 1 (mod phi)
e*d - 1 = k * phi
e*d - 1 = k * ((p-1) * (q-1) * q)
e*d - 1 = k * (p*q*q - q*q - p*q + q)
e*d - 1 = k * (N - q*q - p*q + q)
e*d*q - q = k * q * (N - q*q - p*q + q)
e*d*q - k*q*(N - q*q + q) + k*N = q
e*d*q - k*q*(N - q*q + q) + k*N = q (mod M)
(k)*q3 - (k)*q2 + (d*e - k*N - 1)*q + k*N = 0 (mod M)
Now all we've got to do is dump this equation into the kind of code we
used before, using the handy higher-order function
roots_by_hensel_lift that we wrote earlier:
def factor_pqq(N, partial_d): e = 1667 for k in range(1, e + 1): A = k B = -k C = (partial_d * e) - k * N - 1 D = k * N def f(x): return (A * x * x * x) + (B * x * x) + (C * x) + D solns = roots_by_hensel_lift(f, 2, 1050) for possible_ans in solns: if N % possible_ans == 0: return possible_ans n4 = ns q4 = factor_pqq(ns, nerf_ds) assert q4 is not None assert n4 % q4 == 0 assert n4 % (q4 * q4) == 0 p4 = n4 / (q4 * q4) print "p4 =", str(p4)[:30] + '...' print "q4 =", str(q4)[:30] + '...'
p4 = 220432465124408995064591975926... q4 = 267307309343866797026967908679...
This too takes a little while to compute (in the order of about a
minute), but soon we know the factorization of
Now all that's left is for us to do the same for
that these are of the form
p * q * r, but we know
r due to the shared
r that we computed earlier.
Let's just re-derive a similar attack as before. We reduce the final
equation down to a quadratic equation in
e*d = 1 (mod phi)
e*d - 1 = k * phi
e*d - 1 = k * ((p-1) * (q-1) * (r-1))
e*d - 1 = k * (p*q*r - p*q - p*r - q*r + p + q + r - 1)
e*d - 1 = k * (N - p*q - p*r - q*r + p + q + r - 1)
e*d*p*r - p*r = k*p*r*(N - p*q - p*r - q*r + p + q + r - 1)
(k*r*r - k*r)*p2 + (k*N - r + d*e*r + k*r - k*N*r - k*r*r) + (k*N*r - k*N) = 0
(k*r*r - k*r)*p2 + (k*N - r + d*e*r + k*r - k*N*r - k*r*r) + (k*N*r - k*N) = 0 (mod M)
Since we know
r it is ok to keep around. Let's feed this into similar
code as before, again reusing our handy
Recall that we don't know the order for which one is
n2 and which one
n3. Let's just stick to one order and fix it later if it turns out
to be an issue.
def factor_pqr(N, partial_d, r): e = 1667 for k in range(1, e + 1): A = k*r*r - k*r B = k*N - r + partial_d*e*r + k*r - k*N*r - k*r*r C = k*N*r - k*N def f(x): return (A * x * x) + (B * x) + C solns = roots_by_hensel_lift(f, 2, 1050) for possible_ans in solns: if N % possible_ans == 0: return possible_ans n2 = ns assert n2 % r2 == 0 p2 = factor_pqr(ns, nerf_ds, r2) assert n2 % (p2 * r2) == 0 q2 = n2 / (p2 * r2) n3 = ns r3 = r2 assert n3 % r3 == 0 p3 = factor_pqr(ns, nerf_ds, r3) assert n3 % (p3 * r3) == 0 q3 = n3 / (p3 * r3) print "p2 =", str(p2)[:30] + '...' print "q2 =", str(q2)[:30] + '...' print "r2 =", str(r2)[:30] + '...' print "p3 =", str(p3)[:30] + '...' print "q3 =", str(q3)[:30] + '...' print "r3 =", str(r3)[:30] + '...'
p2 = 902985578846825776692383207600... q2 = 291668652611471250039066078554... r2 = 326199725504488859529927636344... p3 = 142270506848638924547091203976... q3 = 282595361018796512312481928903... r3 = 326199725504488859529927636344...
This takes a tad bit longer, but works out, and then suddenly, now we have all the factorized keys. Let's compute all the private keys.
e = 1667 d1 = gmpy2.powmod(e, -1, (p1-1)*(q1-1)) d2 = gmpy2.powmod(e, -1, (p2-1)*(q2-1)*(r2-1)) d3 = gmpy2.powmod(e, -1, (p3-1)*(q3-1)*(r3-1)) d4 = gmpy2.powmod(e, -1, (p4-1)*(q4-1)*q4)
We also know that the order of the encryptions is
means we should decrypt in the opposite order:
flag = enc_flag flag = pow(flag, d1, n1) flag = pow(flag, d4, n4) flag = pow(flag, d3, n3) flag = pow(flag, d2, n2) print hex(flag)[:30] + '...'
That looks promising. Let's just dump the flag now.
print hex(flag).replace('0x', '').decode('hex')
And there we go!
Overall, this was a super fun challenge to solve. Personally, I think I learnt quite a lot and feel I've got a deeper understanding of both the Coppersmith attack, as well as Hensel's Lemma.
For those wondering, during the CTF, we didn't have such a clean
n1 was solved by a custom solver written in Python by
n3 were solved by a custom solver written in Sage by
solve_mod didn't work
in Sage for some reason). The only part that matches the above code is
the solution for
n4 which I wrote last after understanding Hensel's
lemma much better. Now that I had the clean version for
n4 though, I
couldn't resist cleaning the rest of the solution up to reuse the nice
roots_by_hensel_lift function, and thus this writeup :)
